ATRMax II Variable Angle Horizontal ATR Accessory

  HATR for Inquisitive Minds


(주)비케이인스트루먼트는  PIKE Technologie 사의 공식대리점으로 보다 합리적인 가격에 다양한 제품을 취급하고 있습니다.





DESCRIPTION


The ATRMax II is a high throughput, variable angle horizontal ATR accessory. The design employs a unique optical layout which enables samples to be analyzed over a range of incident angles from 25 to 65 degrees. Variable angle of incidence provides experimental control over the depth of penetration of an IR beam into the sample and the number of beam reflections in the ATR crystal. The ATRMax can be used for depth profiling studies where spectral composition can be analyzed relative to depth of penetration as the angle of incidence is changed.

Selectable angle of incidence

  • 3-12 reflections
  • Flat and trough plates
  • Motorized and temperature controlled options



FEATURES

·  Selectable angle of incidence – 25 to 65 degrees in one degree increments
· 0.5 to 10 micron depth of penetration – dependent on crystal material, angle of incidence, sample’s refractive index and wavelength of IR beam
 – ideal for depth profiling studies
· 3 to 12 reflections of IR beam – dependent upon angle of incidence – ideal for optimizing ATR sampling methods
·  Flat and trough crystal plates for solids, films, powders and liquid samples – optional temperature control for all plates
·  Optional, high-pressure clamp for sampling of films, coatings or powdered samples
·  Automated option with electronic control module and AutoPRO™ software for high-precision experiments
·  Sealed and purgeable optical design to eliminate water vapor and carbon dioxide interferences
